● The oil cylinder should be equipped with a hydraulic lock, which is safe even if the oil pipe is broken;
● It has an emergency stop device and an overload protection device;
● The related actions of increasing the working radius have alarm and limit functions;
● Walking, main arm lifting, main arm extension and retraction, and turntable rotation have delayed buffering functions and anti-impact;
● It has an emergency operating system. If the engine fails during operation, the emergency system can ensure that the arm is retracted;
● The working platform has an automatic leveling function;
● The control cable and hydraulic oil pipe are built into the force arm to prevent erosion by wind and rain and being hung by foreign objects;
● Automatic protection and automatic adjustment when the platform exceeds the working area; when the big arm is lowered, when the operating distance exceeds the safe range, it will automatically retract to ensure that the arm length is within the safe range. When the boom approaches the limit of the operating range, it will automatically slow down and the warning light will flash on the panel;
● The hydraulic outriggers can be leveled individually, and the outriggers have an intelligent automatic leveling function. The boom is not allowed to change its amplitude or extend before the outriggers reach safety and stability, and there is an interlocking device;
● The equipment adopts a dual computer control system, which is safer and more stable. Equipped with an automatic safety and stability device, the dual computer control system calculates the one-to-one correspondence between the load weight and the operating range (extension size) to ensure that all actions are within the safety range and implement safety protection more scientifically;
● Emergency system. During operation, if the machine fails, the emergency system must ensure that the boom is retracted to ensure that the operator reaches the ground safely;
● The advanced safety alarm system ensures that the machine operates in an absolutely stable and safe state;
● The core components are all imported internationally renowned brand products.
● LCD display, computer automatic error detection, fault alarm and self-diagnosis functions when a fault occurs;
●Compact design for indoor and outdoor use
●Detachable Basket
●Self-leveling platform
●Automatic Outriggers leveling
●360°non-continuous turntable rotation
●Hydraulically arms and outrigger interlocks
●Made of high tensile steel
