● The oil cylinder should be equipped with a hydraulic lock, which is safe even if the oil pipe is broken;
● It has an emergency stop device and an overload protection device;
● The related actions that increase the working radius have alarm and limit functions;
● Walking, main arm lifting, main arm extension and retraction, and turntable rotation have delayed buffering functions and anti-impact;
● It has an emergency operating system. If the equipment fails during operation, the emergency system can ensure that the arm is retracted;
● The working platform has an automatic leveling function;
● Automatic protection and automatic adjustment when the platform exceeds the working area;
● The hydraulic legs can be leveled separately and have a manual leveling function.
● The equipment calculates the one-to-one correspondence between the load weight and the operating range (extension size) through the control system to ensure that all actions are within the safety range and implement safety protection more scientifically;
● Emergency system. During operation, if the machine fails, the emergency system can ensure that the arm is retracted to ensure that the operator reaches the ground safely;
● The core components are all imported internationally renowned brand products.
●Compact design for indoor and outdoor use
●Detachable Basket
●Self-leveling platform
●Automatic Outriggers leveling
●360°non-continuous turntable rotation
●Hydraulically arms and outrigger interlocks
●Made of high tensile steel
