● The oil cylinder should be equipped with a hydraulic lock, which is safe even if the oil pipe is broken;
● It has an emergency stop device and an overload protection device;
● The related actions to increase the working radius have alarm and limit functions;
● Walking, main arm lifting, main arm extension and retraction, and turntable rotation have delayed buffering functions and anti-impact;
● It has an emergency operating system. If the equipment fails during operation, the emergency system can ensure that the arm is retracted;
● The working platform has an automatic leveling function; automatic protection and automatic adjustment when the platform exceeds the working area;
● Use a wireless remote control to operate the remote control;
● Control cables and hydraulic oil pipes are built into the arm to prevent erosion by wind and rain and being caught by foreign objects;
● LCD display, with fault alarm in case of fault;
● Diesel engine is equipped with air pre-filter; with anti-restart device to prevent the operator from re-engaging the starter motor when the engine is running, protecting the engine starter motor and flywheel ring gear;
● The engine can be automatically shut down, that is, when the engine temperature is too high or the oil pressure is too low, the engine will stop automatically to prevent engine damage;
● The hydraulic legs can be leveled separately, and the legs have an intelligent automatic leveling function. The arm is not allowed to change amplitude and extend before the legs are safe and stable, and there is an interlocking device;
● The equipment calculates the one-to-one correspondence between the load weight and the operating amplitude (extension size) through the control system to ensure that all actions are within the safety range and implement safety protection more scientifically;
● Emergency system. During operation, if the machine fails, the emergency system can ensure that the arm is retracted to ensure that the operator reaches the ground safely;
● The core components are all imported internationally renowned brand products.
●Compact design for indoor and outdoor use
●Detachable Basket
●Self-leveling platform
●Automatic Outriggers leveling
●360°non-continuous turntable rotation
●Hydraulically arms and outrigger interlocks
●Made of high tensile steel
